Securing OCI API Gateway with JWT Authentication and Functions

Why this matters

High-level takeaways:

• 🔐 Secure APIs at the edge – before requests reach your backend.

• ⚡ Lightweight microservices – let the gateway enforce authentication, not your business logic.

• 🌍 Flexibility – integrate with any identity provider, not only OCI IAM.

• 📜 Compliance-ready – JWT validation helps ensure only trusted, signed requests enter your system.

In other words: this pattern combines security, scalability, and simplicity.

Step 1: Provisioning API Gateway with Terraform

We start with a basic API Gateway resource and a deployment that wires everything together.

resource "oci_apigateway_gateway" "FoggyKitchenAPIGateway" {
  compartment_id = var.compartment_ocid
  endpoint_type  = "PUBLIC"
  subnet_id      = oci_core_subnet.FoggyKitchenPublicSubnet.id
  display_name   = "FoggyKitchenAPIGateway"
}
resource "oci_apigateway_deployment" "FoggyKitchenAPIGatewayDeployment" {
  compartment_id = var.compartment_ocid
  gateway_id     = oci_apigateway_gateway.FoggyKitchenAPIGateway.id
  path_prefix    = "/v1"
  display_name   = "FoggyKitchenAPIGatewayDeployment"
  specification {
    routes {
      backend {
          type        = "ORACLE_FUNCTIONS_BACKEND"
          function_id = module.oci-fk-initiator-function.oci_app_fn.fn_ocid
      }
      methods = ["POST"]
      path    = "/fninitiator"
    }
    request_policies {
      authentication {
        type         = "CUSTOM_AUTHENTICATION"
        function_id  = module.oci-fk-jwt-auth-function.oci_app_fn.fn_ocid
        token_header = "token"
      }
    }
  }
}

👉 Here, the request_policies.authentication section delegates token validation to our custom JWT Auth Function.

Step 2: Deploying the JWT Auth Function with a Terraform Module

Instead of writing long oci_functions_function resources, I use my FoggyKitchen Terraform module to deploy the JWT Auth Function.

module "oci-fk-jwt-auth-function" {
  depends_on               = [
    data.local_file.fnjwtauth_dockerfile,
    data.local_file.fnjwtauth_func_py,
    data.local_file.fnjwtauth_func_yaml,
    data.local_file.fnjwtauth_requirements_txt
  ]
  source                   = "github.com/mlinxfeld/terraform-oci-fk-function"
  tenancy_ocid             = var.tenancy_ocid
  region                   = var.region
  ocir_user_name           = var.ocir_user_name
  ocir_user_password       = var.ocir_user_password
  compartment_ocid         = var.compartment_ocid
  use_my_fn                = true
  fk_fn_name               = "fnjwtauth"
  dockerfile_content       = data.local_file.fnjwtauth_dockerfile.content
  func_py_content          = data.local_file.fnjwtauth_func_py.content
  func_yaml_content        = data.local_file.fnjwtauth_func_yaml.content
  requirements_txt_content = data.local_file.fnjwtauth_requirements_txt.content
  invoke_fn                = false
  use_oci_logging          = false
  use_my_fn_app            = true
  my_fn_app_ocid           = module.oci-fk-initiator-function.oci_app_fn.fn_app_ocid
  use_my_fn_network        = true
  my_fn_subnet_ocid        = oci_core_subnet.FoggyKitchenPrivateSubnet.id
  fn_config                = { "FN_JWT_TOKEN" : "${var.fn_jwt_token}" }
}

This module bundles together:

• OCI Function code (Dockerfile, Python handler, requirements),

• networking setup (private subnet),

• configuration values (JWT secret passed as environment variable).

Step 3: Auth Function code (Python, FDK)

The API Gateway’s CUSTOM_AUTHENTICATION policy invokes our function with a JSON payload containing the client’s token (extracted from the header token).
Our function must respond with {"active": true} to allow the request or {"active": false} to block it.

Here’s the full handler code:

import io
import json
import logging
import datetime
from datetime import timedelta
from fdk import response
def handler(ctx, data: io.BytesIO = None):
    # Defaults for safety
    auth_token = "invalid"
    token = "invalid"
    fnJwtToken = "invalid"
    expiresAt = (datetime.datetime.utcnow() + timedelta(seconds=60))
        .replace(tzinfo=datetime.timezone.utc).astimezone()
        .replace(microsecond=0).isoformat()
    try:
        # JSON body sent by API Gateway: {"token": "..."}
        auth_token = json.loads(data.getvalue())
        token = auth_token.get("token")
        # Function config (set via Terraform: FN_JWT_TOKEN)
        app_context = dict(ctx.Config())
        fnJwtToken = app_context["FN_JWT_TOKEN"]
        # Demo validation: shared secret match
        if token == fnJwtToken:
            return response.Response(
                ctx,
                status_code=200,
                response_data=json.dumps({
                    "active": True,
                    "principal": "foo",
                    "scope": "bar",
                    "clientId": "1234",
                    "expiresAt": expiresAt,
                    "context": {"username": "wally"}
                })
            )
    except (Exception, ValueError) as ex:
        logging.getLogger().info("error parsing json payload: " + str(ex))
    # Reject if anything is off
    return response.Response(
        ctx,
        status_code=401,
        response_data=json.dumps({
            "active": False,
            "wwwAuthenticate": "API-key"
        })
    )

Step 4: Testing the setup

✅ Valid token (success path):

curl -i -X POST -H "token: ${FN_JWT_TOKEN}" "https://your-api-gateway-id.apigateway..oci.customer-oci.com/v1/fninitiator"

Expected: HTTP 200, request reaches backend function.

❌ Invalid token (failure path):

curl -i -X POST -H "token: nope" "https://your-api-gateway-id.apigateway..oci.customer-oci.com/v1/fninitiator"

Expected: HTTP 401 Unauthorized.

FAQ / Q&A

Q: What is OCI API Gateway Terraform used for?
A: It’s used to automate deployment and security of API Gateway in Oracle Cloud Infrastructure, including authentication and backend integration.

Q: Can I secure JWT authentication with OCI API Gateway Terraform?
A: Yes, by combining OCI API Gateway, Functions, and Terraform, you can validate JWT tokens at the edge before traffic hits your backend.

Full source code and training

👉 The full working example of this JWT Authentication pattern is available in my GitHub repo here:
🔗 Lesson 8 – Four Functions, API Gateway, JWT, Streaming, ADB

If you want to go beyond snippets and learn how to combine OCI Functions, API Gateway, JWT validation, Streaming, and Autonomous Database into a real-world serverless architecture, check out my course:
🎓 OCI Serverless Functions with Terraform (2024 Edition)

Wrapping up: Why use OCI API Gateway Terraform for JWT Security

With just a few Terraform resources and a small custom function, you can build a secure API Gateway with JWT authentication in OCI.

This pattern gives you:

• better security (only trusted requests reach your backend),

• better scalability (auth logic scales serverlessly),

• and better maintainability (auth and business logic are separated).

By automating security patterns with OCI API Gateway Terraform, you minimize human error and ensure consistency across environments. f your team is building APIs for production, OCI API Gateway Terraform lets you codify best practices instead of relying on manual steps.
